You are now presented with many settings. Select the ATMEGA328 board under Tools > Board.

#Arduino uno pinout ide install

Install the latest version, then restart your IDE.

Open Tools > Board > Boards Manager and search for the MiniCore. If you already have other URLs, append it separated by a comma. From File > Preferences, add the following Boards Manager URL:

#Arduino uno pinout ide code

Upload the ArduinoISP code to your Uno, setting the usual Board and Programmer. Just connect the 5V wire to the red circle and GND to the black circle as shown below. You can choose to use the Uno’s 5V and GND to power the ATMEGA328P or use an external power source with a 5V regulator. In other words, connect the pins 11-13 on the Uno to the corresponding Arduino pins on the ATMEGA328P, followed by a connection between pin 10 on the Uno and pin 1 on the ATMEGA328P.

Note that pin 1 is denoted by a small dot indentation on your ATMEGA328PĬonnect the Arduino Uno to the breadboard as per below. Most ATMEGA328Ps do not already have the bootloader installed so we need to burn the bootloader on to the ATMEGA328P.īelow is the pinout for the ATMEGA328P.

0.1 uF ceramic capacitors (Labelled 104 usually)įirst, let’s connect the ATMEGA to our breadboard.

Wires (Either use jumper wires or solid core hookup wires which require wire strippers, pliers and cutters).

This configuration allows programming of the ATMEGA328P using the Arduino IDE with almost no restrictions Requirements So we wanted to just use the microcontroller as is for a few reasons - cheaper and more power efficient. For those who do not know the Arduino Uno uses the ATMEGA328P microcontroller. But essentially, we wanted to use the ATMEGA328P instead of the Arduino Uno. This project was part of an even bigger project.
